Maswell Cellular 5G Antenna Ultra wideband high gain 9.5dBi 433MHz-10.6GHz for All The 5G 4G LTE 3G Bands WiFi Harlow WiFi 2.4 WiFi 6E, LORA, CB Radio and DAB FM Bands Directional Aerial

Description

• Cellular Communications bands: 5G ,4G , 3G and GSM around the globe All Supported
• WiFi/Bluetooth/Zigbee applications: WiFi Harlow, WiFi 2.4GHz, WiFi 5GHz, WiFi 6, WiFi 6E All Supported
• UWB Communicaitons 3.1-10.6GHz All Supported
• CB Radios at 477MHz band: All Supported
• M2M communication, IOT, Helium communication All Supported LORA Communication All Supported

ITEM ID:AN.UWB.int4.433.10000.SMA
Maswell Cellular 5G antenna high gain 9.5dBi 433MHz-10.6GHz for all the 5G 4G LTE 3G bands Wifi harlow Wifi 2.4 Wifi 6E LORA antennas with CB radio and DAB FM bands directional aerial
Antenna Specification Frequency Range:433MHz-10.6GHz (High Gain)FM and DAB: Compatible
Polarization:Linear
Gain:9dBi typical
Efficiency:>50%
Mechanical Dimension:250mm *317.8mm
Connector:SMA female
Environmental/b> Operating Temperature-40~+85
Relative HumidityUp to 95%
Vibration:10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly:ROHS Compliant

>Package Weight:150g
Dimension:281mm*382mm

5G/4G/3G/GSM FREQUENCY: 433MHz-10.6GHz.Cellular Communications bands: 5G ,4G , 3G and GSM around the globe All Supported.WiFi/Bluetooth/Zigbee applications: WiFi Harlow, WiFi 2.4GHz,WiFi 5GHz, WiFi 6, WiFi 6E All Supported.UWB Communicaitons 3.1-10.6GHz All Supported.CB Radios at 477MHz band: All Supported.M2M communication, IOT, Helium communication All Supported LORA Communication All Supported.
